995110

Weidmüller
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description Wire Board Terminal Block
PDF
/
Inventory: 6449
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Ways 7
Safety Approval UL; VDE; CSA
Mating Orientation 45° (135°) Angle with Board
Wire Termination Screw - Clamping Yoke, Tension Sleeve
Screw Thread M3
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Voltage 300V
Wire Gauge 12-26 AWG
Number of Contacts 7
Reach Compliance Code compliant
Pitch 0.197 5.00mm
HTS Code 8536.69.40.40
Number of Rows 1
Color Black
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Interlocking (Side)
Series Omnimate LP
Packaging Bulk
Operating Temperature -20°C~100°C

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant

Physical

Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 5 Weeks
