995004
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Omnimate LP M3 Non-RoHS Compliant Straight Wire Board Terminal Block 26AWG -20C~100C 15A 300V
PDF
/
Inventory: 4036
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Screw Thread M3
Wire Termination Screw - Clamping Yoke, Tension Sleeve
Mating Orientation Horizontal with Board
Safety Approval UL; VDE; CSA
Number of Ways 6
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Voltage 300V
Wire Gauge 12-26 AWG
Number of Contacts 6
Reach Compliance Code compliant
Orientation Straight
Pitch 0.197 5.00mm
Number of Rows 1
Color Orange
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Interlocking (Side)
Series Omnimate LP
Packaging Bulk
Operating Temperature -20°C~100°C
Physical
Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 4 Weeks
