1870150000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Conn Spring Cage 3 POS 5mm Solder ST Thru-Hole 10A Tube
PDF
/
Inventory: 7561
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Fastening Method PUSH-ON
Stripping Length 8mm
Hole Diameter 1.1 mm
Wire Termination Screwless - Push Button Clamp
Mating Orientation Vertical with Board
Safety Approval UL; VDE; CSA
Number of Ways 3
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 24 AWG
Current 12A
Number of Levels 1
Wire Gauge 16-24 AWG
Number of Contacts 3
Approval Agency CSA, cURus
Current Rating 10A
Orientation Straight
Pitch 0.197 5.00mm
Additional Feature GLASS FILLED LCP, 94V-0
Voltage - Rated 300V
Number of Rows 1
Color Black
ECCN Code EAR99
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Omnimate LSF-SMT
Published 2015
Packaging Tube
Operating Temperature -50°C~120°C
Physical
Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 11 Weeks
