1811160000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
STANDARD: UL 94V-0 Wire Board Terminal Block
PDF
/
Inventory: 2965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic, Wemid
Contact Material - Plating Copper Alloy - Tin Plated
Technical
Operating Temperature -50°C~120°C
Packaging Bulk
Series Omnimate LS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Color Green
Number of Rows 1
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Pitch 0.200 5.08mm
Orientation Right Angle
Number of Contacts 11
Wire Gauge 14-28 AWG
Voltage 300V
Number of Levels 1
Current 15A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 14 AWG
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.4-0.5 Nm (3.5-4.4 Lb-In)
Number of Ways 11
Safety Approval UL; CSA
Mating Orientation Horizontal with Board
Wire Termination Screw - Clamping Yoke, Tension Sleeve
Screw Thread M2.5
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
