282913-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
TERM BLK 2P SIDE ENT 5.08MM PCB
PDF
/
Inventory: 5615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass - Nickel Plated
Screw Material - Plating Brass - Nickel Plated
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2003
Series Buchanan
Feature Interlocking (Side), Mid Wire Entry Level
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Number of Positions 2
Color Green
Number of Rows 2
Additional Feature PA66, 94V-0
HTS Code 8536.69.40.40
Pitch 0.200 5.08mm
Orientation Straight
Wire Gauge 12-30 AWG
Voltage 300V
ELV Compliant
Current 24A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Number of Decks 2
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Torque - Screw 0.79 Nm (7.0 Lb-In)
Number of Ways 4
Safety Approval UL
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Screw Thread M3
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
