1985920
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Fixed Terminal Blocks MKDSN 2.5/ 2 HT BK
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.953063
≥1 USD $0.953063
≥10 USD $0.899115
≥100 USD $0.848214
≥500 USD $0.800207
≥1000 USD $0.754908
Inventory: 3656
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Weight 2.850006g
Technical
Packaging Bulk
Published 2003
Series COMBICON MKDSN
Feature Interlocking (Side)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Connector Type Screw
Color Black
Number of Rows 1
Voltage - Rated 320V
Additional Feature PA, UL 94V-0
HTS Code 8536.69.40.40
Pitch 0.197 5.00mm
Current Rating 16A
Wire Gauge 12-30 AWG
Voltage 300V
Number of Levels 1
Current 20A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 24 AWG
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways 2
Safety Approval UL
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Screw Thread M3
Number of Positions Per Level 2
Dimensions
Height 15mm
Length 9.5mm
Width 18.5mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
