1890471
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Conn PC Terminal Block 2 POS 3.81mm Solder ST Thru-Hole 12A
PDF
/
Buying Options
Total Price: USD $2.32
Unit Price: USD $2.3232
≥1 USD $2.3232
≥10 USD $2.26248
≥100 USD $2.11464
≥500 USD $1.945504
≥1000 USD $1.909037
Inventory: 56
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 3.628739kg
Technical
Packaging Bulk
Published 2010
Series COMBICON FFKDSA
Feature Interlocking (Side), Lever Actuated
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
Number of Positions 2
Color Green
Gender Female
Voltage - Rated 160V
Pitch 0.150 3.81mm
Current Rating 12A
Wire Gauge 16-26 AWG
Voltage 300V
Number of Levels 1
Current 6A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 16 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Mating Orientation Vertical with Board
Wire Termination Screwless - Spring Cage, Tension Clamp
Dimensions
Length 12.7mm
Compliance
RoHS Status RoHS Compliant
