1823366
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
COMBICON SPT-THR RoHS Compliant 2015 Vertical with Board Wire Board Terminal Block 24AWG 10A 300V 0.150 3.81mm
PDF
/
Inventory: 1149
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Number of Positions Per Level 8
Wire Termination Screwless - Leg Spring, Push-In Spring
Mating Orientation Vertical with Board
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 24 AWG
Current 10A
Number of Levels 1
Voltage 300V
Wire Gauge 16-24 AWG
Pitch 0.150 3.81mm
Color Black
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON SPT-THR
Published 2015
Packaging Tape & Reel (TR)
Physical
Contact Material - Plating Tin Plated
Housing Material Liquid Crystal Polymer (LCP)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
