Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description Fixed Terminal Blocks 41A 800 V 12-pos GRN PC terminal block
PDF
/
Buying Options
Total Price: USD $67.41
Unit Price: USD $67.412163
≥1 USD $67.412163
≥200 USD $26.898695
≥500 USD $25.999359
≥1000 USD $25.555599
Inventory: 1649
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Fastening Method SPRING LOADED
Wire Cross Section 6 mm2
Wire Termination Screwless - Spring Cage, Tension Clamp
Mating Orientation Horizontal with Board
Safety Approval UL
Number of Ways 12
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 8 AWG
Wire Gauge (Max) 24 AWG
Current 35A
Number of Levels 1
Voltage 600V
Wire Gauge 8-24 AWG
Current Rating 41A
Pitch 0.295 7.50mm
HTS Code 8536.69.40.40
Additional Feature PA, UL 94V0
Voltage - Rated 1kV
Gender Female
Number of Rows 1
Color Green
Number of Positions 12
ECCN Code EAR99
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON SPT
Published 2011
Packaging Bulk

Physical

Weight 1.000171kg
Housing Material Polyamide (PA), Nylon
Material Polyamide
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
