1713969
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Phoenix Contact COMBICON MKDS Series 6.35mm Pitch PCB Terminal Block with Screw Termination, Through Hole, 6 Way
PDF
/
Buying Options
Total Price: USD $4.49
Unit Price: USD $4.489648
≥1 USD $4.489648
≥10 USD $4.23552
≥100 USD $3.995778
≥500 USD $3.769597
≥1000 USD $3.556223
Inventory: 1078
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Contact Material - Plating Tin Plated
Technical
Packaging Bulk
Published 2015
Series COMBICON MKDS
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Color Green
Number of Rows 1
Voltage - Rated 1kV
Additional Feature UL94V-0
Pitch 0.250 6.35mm
Depth 21.5mm
Current Rating 32A
Wire Gauge 10-30 AWG
Voltage 300V
Number of Levels 1
Current 30A
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Positions Per Level 6
Number of Ways 6
Safety Approval CSA; CUL; GOST; UL
Mating Orientation Horizontal with Board
Wire Termination Screw - Leaf Spring, Wire Guard
Screw Thread M3
Wire Cross Section 4 mm2
Dimensions
Length 19.05mm
Compliance
RoHS Status RoHS Compliant
