OSTHT174080
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
OSTHT ROHS3Compliant Steel Angled Wire Board Terminal Block 28AWG 105C 15A 300V
PDF
/
Inventory: 6745
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Brass
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Contact Material - Plating Brass
Clamp Material - Plating Steel, Stainless
Technical
Operating Temperature -30°C~105°C
Packaging Bulk
Series OSTHT
Feature Interlocking (Side), Lever Actuated
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color Gray
Pitch 0.400 10.16mm
Wire Gauge 12-28 AWG
Voltage 300V
Plating Steel
Number of Levels 1
Current 15A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 12 AWG
Positions Per Level 17
Mating Orientation Angled
Wire Termination Screwless - Leg Spring, Push-In Spring
Number of Positions Per Level 17
Compliance
RoHS Status ROHS3 Compliant
