RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description OSTHC ROHS3Compliant Vertical with Board Interlocking (Side) Wire Board Terminal Block 26AWG -30C~105C 2A 150V
PDF
/
Inventory: 6374
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Fastening Method SPRING LOADED
Number of Positions Per Level 19
Wire Termination Screwless - Leg Spring, Push-In Spring
Mating Orientation Vertical with Board
Safety Approval CUL; UL
Number of Ways 19
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 26 AWG
Current 2A
Number of Levels 1
Voltage 150V
Wire Gauge 20-26 AWG
Pitch 0.098 2.50mm
Number of Rows 1
Color Gray
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series OSTHC
Packaging Bulk
Operating Temperature -30°C~105°C

Physical

Contact Material - Plating Phosphor Bronze
Housing Material Thermoplastic
Mounting Type Through Hole, Kinked Pin
Mount Through Hole
Contact Plating Bronze

Supply Chain

Factory Lead Time 8 Weeks
