OSTEB070150
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
OSTEB M3 ROHS3Compliant Brass Steel Wire Board Terminal Block 22AWG 105C 20A 300V
PDF
/
Inventory: 4857
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Brass, Tin
Mount Through Hole
Mounting Type Through Hole
Number of Pins 7
Housing Material Thermoplastic
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass
Screw Material - Plating Steel - Zinc Plated
Technical
Operating Temperature -30°C~105°C
Packaging Bulk
Series OSTEB
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color Green
Pitch 0.197 5.00mm
Wire Gauge 12-22 AWG
Voltage 300V
Plating Brass, Steel
Number of Levels 2
Current 20A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Torque - Screw 0.49 Nm (4.3 Lb-In)
Positions Per Level 7
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Screw Thread M3
Number of Positions Per Level 7
Compliance
RoHS Status ROHS3 Compliant
