39920-0103
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Wire Board Terminal Block
PDF
/
Inventory: 6714
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Copper, Tin
Mount Through Hole
Housing Material Thermoplastic
Technical
Termination Screw
Number of Positions 3
Max Operating Temperature 130°C
Min Operating Temperature 0°C
Color Black
Number of Rows 1
Voltage - Rated 600V
Pitch 15.0114mm
Orientation Vertical
Current Rating 85A
Housing Color Black
Insulation Resistance 50GOhm
Voltage 600V
Number of Circuits 3
Plating Brass, Bronze, Tin
Number of Levels 1
Current 85A
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 3 AWG
Number of Positions Per Level 3
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
