0399540103
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Wire Board Terminal Block
PDF
/
Inventory: 8431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 24.8mm
Technical
Number of Positions Per Level 3
Screw Thread M3
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Horizontal with Board
Positions Per Level 3
Torque - Screw 0.56 Nm (5.0 Lb-In)
Wire/Cable Gauge 12 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 22 AWG
Current 20A
Number of Levels 1
Plating Brass, Bronze, Tin
Max Supply Voltage 600V
Number of Circuits 3
Voltage 600V
Wire Gauge 12-22 AWG
Housing Color Black
Number of Contacts 3
Depth 15.6mm
Orientation Straight
Pitch 0.315 8.00mm
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Eurostyle 39954
Packaging Bulk
Operating Temperature -40°C~130°C
Physical
Screw Material - Plating Bronze - Tin Plated
Clamp Material - Plating Brass - Nickel Plated
Contact Material - Plating Brass - Tin Plated
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Brass, Tin
Contact Material Brass, Bronze
Supply Chain
Factory Lead Time 11 Weeks
