0398804508
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Eurostyle 39880 M3 ROHS3Compliant Horizontal with Board Wire Board Terminal Block -40C~105C 13.5A 300V 0.200 5.08mm
PDF
/
Inventory: 3112
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Screw Thread M3
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Horizontal with Board
Positions Per Level 4
Torque - Screw 0.68 Nm (6 Lb-In)
Current 13.5A
Number of Levels 2
Voltage 300V
Wire Gauge 16-30 AWG
Pitch 0.200 5.08mm
Color Green
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series Eurostyle 39880
Packaging Bulk
Operating Temperature -40°C~105°C
Physical
Screw Material - Plating Bronze - Nickel Plated
Clamp Material - Plating Brass - Nickel Plated
Contact Material - Plating Copper - Tin Plated
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Supply Chain
Factory Lead Time 15 Weeks
