0395943010
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Eurostyle ESE 39594 ROHS3Compliant Horizontal with Board Brass Wire Board Terminal Block -40C~105C 15A 300V 0.200 5.08mm
PDF
/
Inventory: 2741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass
Screw Material - Plating Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39594
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Green
Pitch 0.200 5.08mm
Wire Gauge 12-30 AWG
Voltage 300V
Number of Levels 1
Current 15A
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.51 Nm (4.5 Lb-In)
Positions Per Level 10
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Compliance
RoHS Status ROHS3 Compliant
