0395935116
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Eurostyle ESE 39593 ROHS3Compliant Vertical with Board Interlocking (Side) Positions Stamped Wire Board Terminal Block -40C~105C 10A 300V 0.197 5.00mm
PDF
/
Inventory: 6432
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Vertical with Board
Positions Per Level 16
Torque - Screw 0.4 Nm (3.5 Lb-In)
Current 10A
Number of Levels 1
Voltage 300V
Wire Gauge 16-24 AWG
Pitch 0.197 5.00mm
Color Green
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side), Positions Stamped
Series Eurostyle ESE 39593
Packaging Bulk
Operating Temperature -40°C~105°C
Physical
Screw Material - Plating Steel
Clamp Material - Plating Brass
Contact Material - Plating Brass - Tin-Lead Plated
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Through Hole
Supply Chain
Factory Lead Time 20 Weeks
