0395933023
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Eurostyle ESE 39593 ROHS3Compliant Horizontal with Board Brass Wire Board Terminal Block -40C~105C 15A 300V 0.197 5.00mm
PDF
/
Inventory: 2615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage 300V
Number of Levels 1
Current 15A
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.51 Nm (4.5 Lb-In)
Positions Per Level 23
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Wire Gauge 14-22 AWG
Pitch 0.197 5.00mm
Color Green
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Eurostyle ESE 39593
Packaging Bulk
Operating Temperature -40°C~105°C
Compliance
RoHS Status ROHS3 Compliant
Physical
Screw Material - Plating Steel
Clamp Material - Plating Brass
Contact Material - Plating Brass - Tin Plated
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Through Hole
Supply Chain
Factory Lead Time 17 Weeks
