0395447014
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Conn Eurostyle Block 14 POS 5.08mm Solder ST Thru-Hole 15A/Contact
PDF
/
Inventory: 4572
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Contact Plating Brass, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass
Screw Material - Plating Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39544
Feature Positions Stamped
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Color Black
Pitch 0.200 5.08mm
Orientation Straight
Reach Compliance Code unknown
Wire Gauge 12-30 AWG
Voltage 300V
Plating Brass, Steel
Number of Levels 1
Current 15A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.51 Nm (4.5 Lb-In)
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Number of Positions Per Level 14
Compliance
RoHS Status ROHS3 Compliant
