0395438309
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Conn Eurostyle Block 9 POS 5mm Solder Thru-Hole 10A/Contact Eurostyle?
PDF
/
Inventory: 5849
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Contact Material Brass, Steel
Contact Plating Brass, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass
Screw Material - Plating Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39543
Feature Positions Stamped
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Color Black
Pitch 0.197 5.00mm
Depth 12.3mm
Number of Contacts 9
Wire Gauge 14-22 AWG
Max Supply Voltage 300V
Plating Brass, Steel
Number of Levels 1
Current 10A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 14 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.34 Nm (3.0 Lb-In)
Positions Per Level 9
Mating Orientation 45° (135°) Angle with Board
Wire Termination Screw - Rising Cage Clamp
Dimensions
Length 45.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
