0395437113
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Eurostyle ESE 39543 ROHS3Compliant Brass Steel Right Angle Wire Board Terminal Block 24AWG -40C~105C 10A 300V
PDF
/
Inventory: 3725
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Brass, Steel
Contact Plating Brass, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass
Screw Material - Plating Steel
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39543
Feature Interlocking (Side), Positions Stamped
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Color Black
Pitch 0.197 5.00mm
Orientation Right Angle
Depth 10mm
Number of Contacts 13
Wire Gauge 16-24 AWG
Max Supply Voltage 300V
Plating Brass, Steel
Number of Levels 1
Current 10A
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 16 AWG
Wire/Cable Gauge 16 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.4 Nm (3.5 Lb-In)
Positions Per Level 13
Mating Orientation Vertical with Board
Wire Termination Screw - Rising Cage Clamp
Dimensions
Length 65mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
