TB009-508-24BE

CUI Devices
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description TB009-508 M3 RoHS Compliant Horizontal with Board Wire Board Terminal Block -40C~105C 20A 300V 0.200 5.08mm
PDF
/
Inventory: 2746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Copper Alloy - Tin Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Screw Material - Plating Steel - Zinc Plated

Technical

Operating Temperature -40°C~105°C
Packaging Bulk
Series TB009-508
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Color Blue
Pitch 0.200 5.08mm
Wire Gauge 12-26 AWG
Voltage 300V
Number of Levels 1
Current 20A
Torque - Screw 0.5 Nm (4.4 Lb-In)
Positions Per Level 24
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Screw Thread M3

Compliance

RoHS Status RoHS Compliant
