A-TB500-VI17H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
A-TB500 M3 ROHS3Compliant 2014 Wire Board Terminal Block 28AWG -30C~105C 16A 300V
PDF
/
Inventory: 5265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Contact Material - Plating Brass
Screw Material - Plating Steel - Zinc Plated
Technical
Operating Temperature -30°C~105°C
Packaging Bulk
Published 2014
Series A-TB500
Feature Interlocking (Side)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Color Green
Pitch 0.197 5.00mm
Wire Gauge 12-28 AWG
Voltage 300V
Plating Steel
Number of Levels 1
Current 16A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 12 AWG
Torque - Screw 0.4 Nm (3.5 Lb-In)
Positions Per Level 17
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Screw Thread M3
Compliance
RoHS Status ROHS3 Compliant
