A-TB500-TR17H

Assmann WSW Components
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description A-TB500 M2.5 ROHS3Compliant 2010 Wire Board Terminal Block 22AWG -40C~115C 20A 300V
PDF
/
Inventory: 1372
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Series A-TB500
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Color Green
Pitch 0.197 5.00mm
Wire Gauge 12-22 AWG
Voltage 300V
Plating Steel
Number of Levels 1
Current 20A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 12 AWG
Torque - Screw 0.27 Nm (2.4 Lb-In)
Positions Per Level 17
Mating Orientation Horizontal with Board
Wire Termination Screw - Pressure Clip
Screw Thread M2.5
Published 2010
Packaging Bulk
Operating Temperature -40°C~115°C

Compliance

RoHS Status ROHS3 Compliant

Physical

Screw Material - Plating Steel - Zinc Plated
Clamp Material - Plating Steel - Zinc Plated
Contact Material - Plating Brass - Tin Plated
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Brass, Tin

Supply Chain

Factory Lead Time 23 Weeks
