A-TB500-TD23
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
A-TB500 M2.6 ROHS3Compliant 2010 Wire Board Terminal Block 22AWG -40C~115C 16A 250V
PDF
/
Buying Options
Total Price: USD $6.8
Unit Price: USD $6.796883
≥1 USD $6.796883
≥200 USD $2.712451
≥500 USD $2.621861
≥1000 USD $2.577223
Inventory: 5627
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Screw Thread M2.6
Wire Termination Screw - Leaf Spring, Wire Guard
Mating Orientation Vertical with Board
Positions Per Level 23
Torque - Screw 0.3 Nm (2.6 Lb-In)
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 22 AWG
Current 16A
Number of Levels 1
Plating Steel
Voltage 250V
Wire Gauge 14-22 AWG
Pitch 0.197 5.00mm
Color Blue
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Interlocking (Side)
Series A-TB500
Published 2010
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Screw Material - Plating Steel - Zinc Plated
Clamp Material - Plating Steel, Stainless
Contact Material - Plating Brass - Tin Plated
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Brass, Tin
Supply Chain
Factory Lead Time 23 Weeks
