SCM153100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
SCM RoHS Compliant 2005 Steel Wire Board Terminal Block 28AWG 125C 20A 300V
PDF
/
Buying Options
Total Price: USD $12.01
Unit Price: USD $12.007783
≥1 USD $12.007783
≥200 USD $4.790772
≥500 USD $4.631911
≥1000 USD $4.551824
Inventory: 2880
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Brass, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Steel, Stainless
Technical
Operating Temperature 125°C
Packaging Tray
Published 2005
Series SCM
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
Color Black
Number of Rows 1
Pitch 0.197 5.00mm
Number of Contacts 15
Wire Gauge 12-28 AWG
Voltage 300V
Number of Circuits 15
Plating Steel
Number of Levels 1
Current 20A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 12 AWG
Positions Per Level 15
Mating Orientation Angled
Wire Termination Screwless - Spring Cage, Tension Clamp
Number of Positions Per Level 15
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
