ESTM08300

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description Wire Board Terminal Block
PDF
/
Inventory: 1691
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Number of Positions Per Level 8
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Horizontal with Board
Positions Per Level 8
Torque - Screw 0.5 Nm (4.4 Lb-In)
Wire Gauge (Min) 11 AWG
Wire Gauge (Max) 30 AWG
Current 24A
Number of Levels 1
Voltage 300V
Wire Gauge 11-30 AWG
Pitch 0.295 7.50mm
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 110°C
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series ESTM
Published 2012
Packaging Tray
Operating Temperature -40°C~110°C

Physical

Screw Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Polyamide (PA66), Nylon 6/6
Number of Pins 8
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 8 Weeks
