ESLT06140
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Wire Board Terminal Block
PDF
/
Inventory: 4484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Number of Pins 6
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Copper Alloy - Tin Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Screw Material - Plating Copper Alloy - Nickel Plated
Technical
Operating Temperature -40°C~110°C
Packaging Tray
Published 2012
Series ESLT
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Max Operating Temperature 110°C
Min Operating Temperature -40°C
Color Black
Pitch 0.197 5.00mm
Wire Gauge 14-30 AWG
Voltage 300V
Number of Levels 2
Current 13.5A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 14 AWG
Torque - Screw 0.5 Nm (4.4 Lb-In)
Positions Per Level 3
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Number of Positions Per Level 3
Compliance
RoHS Status RoHS Compliant
