ESLT04140
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
ESLT RoHS Compliant 2012 Horizontal with Board Wire Board Terminal Block 30AWG 110C 13.5A 300V
PDF
/
Inventory: 1649
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Number of Positions Per Level 2
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Horizontal with Board
Positions Per Level 2
Torque - Screw 0.5 Nm (4.4 Lb-In)
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 30 AWG
Current 13.5A
Number of Levels 2
Voltage 300V
Wire Gauge 14-30 AWG
Pitch 0.197 5.00mm
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 110°C
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series ESLT
Published 2012
Packaging Tray
Operating Temperature -40°C~110°C
Physical
Screw Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Polyamide (PA66), Nylon 6/6
Number of Pins 4
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 8 Weeks
