ELVM06900

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description Wire Board Terminal Block
PDF
/
Inventory: 8006
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Termination Screw
Color Black
Number of Rows 1
Pitch 0.150 3.81mm
Orientation Right Angle
Depth 11.43mm
Wire Gauge 16-28 AWG
Voltage 300V
Max Supply Voltage 300V
Max Current Rating 12A
Number of Levels 1
Current 12A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 16 AWG
Torque - Screw 0.25 Nm (2.2 Lb-In)
Positions Per Level 6
Mating Orientation Vertical with Board
Wire Termination Screw - Rising Cage Clamp
Number of Positions Per Level 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELVM
Published 2012
Packaging Tray
Operating Temperature 125°C

Dimensions

Length 22.86mm

Compliance

RoHS Status RoHS Compliant

Physical

Screw Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Contact Material - Plating Brass - Tin Plated
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Through Hole
Mount Through Hole
Contact Plating Brass, Tin
Contact Material Brass

Supply Chain

Factory Lead Time 8 Weeks
