ELVM04900
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Wire Board Terminal Block
PDF
/
Buying Options
Total Price: USD $3.85
Unit Price: USD $3.853362
≥1 USD $3.853362
≥200 USD $1.537406
≥500 USD $1.486203
≥1000 USD $1.461258
Inventory: 9329
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 15.24mm
Technical
Number of Positions Per Level 4
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Vertical with Board
Positions Per Level 4
Torque - Screw 0.25 Nm (2.2 Lb-In)
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 28 AWG
Current 12A
Number of Levels 1
Max Current Rating 12A
Max Supply Voltage 300V
Voltage 300V
Wire Gauge 16-28 AWG
Depth 11.43mm
Orientation Right Angle
Pitch 0.150 3.81mm
Number of Rows 1
Color Black
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ELVM
Published 2012
Packaging Tray
Operating Temperature 125°C
Physical
Screw Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Contact Material - Plating Brass - Tin Plated
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Through Hole
Mount Through Hole
Contact Plating Brass, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
