ELMP04041
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
TERM BLK 4P SIDE ENT 10.16MM PCB
PDF
/
Inventory: 6833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Contact Material - Plating Copper Alloy - Tin Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Screw Material - Plating Steel - Zinc Plated
Technical
Operating Temperature -40°C~120°C
Packaging Bulk
Published 2008
Series ELMP
Feature Interlocking (Side)
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Connector Type Screw
Color Black
Pitch 0.400 10.16mm
Wire Gauge 8-18 AWG
Voltage 300V
Plating Steel
Number of Levels 1
Current 60A
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 8 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 1.36 Nm (12 Lb-In)
Positions Per Level 4
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Compliance
RoHS Status RoHS Compliant
