EL3M602B00

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description EL3M RoHS Compliant 2012 Horizontal with Board Wire Board Terminal Block 30AWG 105C 20A 300V
PDF
/
Buying Options
Total Price: USD $44.48
Unit Price: USD $44.477113
≥1 USD $44.477113
≥200 USD $17.747782
≥500 USD $17.154351
≥1000 USD $16.861575
Inventory: 5095
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Number of Positions Per Level 20
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Horizontal with Board
Positions Per Level 20
Torque - Screw 0.79 Nm (7.0 Lb-In)
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 30 AWG
Current 20A
Number of Levels 3
Voltage 300V
Wire Gauge 12-30 AWG
Pitch 0.200 5.08mm
Color Black
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series EL3M
Published 2012
Packaging Tray
Operating Temperature 105°C

Physical

Screw Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Polyamide (PA), Nylon
Number of Pins 60
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 8 Weeks
