EL3M092G00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
EL3M RoHS Compliant 2012 Horizontal with Board Wire Board Terminal Block 30AWG 105C 20A 300V
PDF
/
Inventory: 5157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Number of Positions Per Level 3
Wire Termination Screw - Rising Cage Clamp
Mating Orientation Horizontal with Board
Positions Per Level 3
Torque - Screw 0.79 Nm (7.0 Lb-In)
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 30 AWG
Current 20A
Number of Levels 3
Voltage 300V
Wire Gauge 12-30 AWG
Pitch 0.200 5.08mm
Color Green
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Interlocking (Side)
Series EL3M
Published 2012
Packaging Tray
Operating Temperature 105°C
Physical
Screw Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Contact Material - Plating Copper Alloy - Tin Plated
Housing Material Polyamide (PA), Nylon
Number of Pins 9
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 8 Weeks
