EL2M282G00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
EL2M RoHS Compliant 2012 Horizontal with Board Wire Board Terminal Block 30AWG 105C 20A 300V
PDF
/
Buying Options
Total Price: USD $25.27
Unit Price: USD $25.272012
≥1 USD $25.272012
≥200 USD $10.084385
≥500 USD $9.74697
≥1000 USD $9.580231
Inventory: 1608
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Contact Material - Plating Copper Alloy - Tin Plated
Clamp Material - Plating Copper Alloy - Nickel Plated
Screw Material - Plating Copper Alloy - Nickel Plated
Technical
Operating Temperature 105°C
Packaging Tray
Published 2012
Series EL2M
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Color Green
Pitch 0.200 5.08mm
Wire Gauge 12-30 AWG
Voltage 300V
Number of Levels 2
Current 20A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 12 AWG
Torque - Screw 0.79 Nm (7.0 Lb-In)
Positions Per Level 14
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp
Number of Positions Per Level 14
Compliance
RoHS Status RoHS Compliant
