1780850000

Weidmüller
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description TERM BLK POST SGL 1POS 17.8MM
PDF
/
Buying Options
Total Price: USD $12.64
Unit Price: USD $12.6368
≥1 USD $12.6368
≥10 USD $11.12056
≥100 USD $10.488896
≥500 USD $9.983424
≥1000 USD $9.79396
≥3000 USD $8.530192
Inventory: 585
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Width 17.8mm
Length 2.638 67.00mm
Height 54.5mm

Technical

Wire Cross Section 35 mm2
Current - IEC 125A
Wire Gauge or Range - mm2 2.5-35mm2
Safety Approval UL; CSA; CE
Number of Ways 1
Wire Gauge or Range - AWG 2-14 AWG
Number of Decks 1
Wire/Cable Gauge 2 AWG
Wire Gauge (Min) 2 AWG
Wire Gauge (Max) 14 AWG
Current 115A
Voltage 1kV
Housing Color Beige
Number of Contacts 1
Approval Agency CE, CSA, cURus
Termination Style Stud
Current Rating 125A
Orientation Straight
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Voltage - Rated 8kV
Number of Rows 1
Type Post - Single
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series W
Published 2003
Operating Temperature -50°C~120°C

Physical

Material - Insulation Thermoplastic, Wemid
Housing Material Nylon
Mounting Type DIN Rail
Mount Cable, DIN Rail

Supply Chain

Factory Lead Time 8 Weeks
