1712980000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
Weidmüller 1712980000 ZDUB 2.5-2/4AN/RC BL 0,5 - 4 mm2 Blue
PDF
/
Inventory: 7697
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Direct Mount
Material - Insulation Thermoplastic, Wemid
Technical
Operating Temperature -50°C~120°C
Published 2012
Series Z
Feature Engagement Pin
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Middle
Number of Positions 4
Number of Rows 1
Voltage - Rated 8kV
Current Rating 24A
Termination Style Spring Cage
Approval Agency CE, CSA, IEC, UR
Housing Color Blue
Voltage 600V
Number of Levels 1
Current 21A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 12 AWG
Voltage - UL 600V
Number of Decks 1
Wire Gauge or Range - AWG 12-26 AWG
Current - UL 20A
Voltage - IEC 800V
Safety Approval UL; CSA; CE
Wire Gauge or Range - mm2 0.5-4mm2
Stripping Length 10mm
Wire Cross Section 2.5 mm2
Fastening Method SPRING LOADED
Dimensions
Height 29mm
Length 1.319 33.50mm
Width 10.2mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
