1704520000
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
POLYAMIDE Specialized Terminal Block
PDF
/
Inventory: 9470
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 5.1mm
Length 1.319 33.50mm
Height 24.003mm
Technical
Fastening Method SCREW
Stripping Length 10mm
Current - IEC 24A
Wire Gauge or Range - mm2 0.5-4mm2
Safety Approval UL; VDE; CSA
Voltage - IEC 800V
Wire Gauge or Range - AWG 12-26 AWG
Voltage - UL 600V
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 20A
Number of Levels 1
Voltage 600V
Housing Color Orange
Termination Style Spring Cage
HTS Code 8536.69.40.40
Additional Feature POLYAMIDE
Number of Positions 2
Type End Terminal
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Series Z
Operating Temperature -50°C~120°C
Physical
Material - Insulation Thermoplastic, Wemid
Housing Material Nylon
Mounting Type Direct Mount
