1011780000

Weidmüller
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description Specialized Terminal Block
PDF
/
Inventory: 6057
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Terminal Width 6.0mm
Width 6mm
Length 2.362 60.00mm
Height 46.99mm

Technical

Stripping Length 10mm
Current - IEC 32A
Wire Gauge or Range - mm2 4mm2
Safety Approval UL; VDE; CSA
Voltage - IEC 400V
Wire Gauge or Range - AWG 10-22 AWG
Voltage - UL 600V
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 22 AWG
Current 35A
Number of Levels 1
Voltage 600V
Housing Color Blue
Termination Style Special, Hybrid
HTS Code 8536.69.40.40
Number of Positions 2
Type Bus Bar - Side
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Series W

Physical

Material - Insulation Thermoplastic, Wemid
Housing Material Nylon
Mounting Type DIN Rail
Mount DIN Rail
