1010900000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
TERM BLK BUS BAR 2POS 9.9MM BLUE
PDF
/
Inventory: 7961
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 9.9mm
Length 2.362 60.00mm
Height 46.99mm
Technical
Stripping Length 12mm
Current - IEC 57A
Wire Gauge or Range - mm2 1.5-16mm2
Safety Approval UL; CSA; CE
Voltage - IEC 400V
Wire Gauge or Range - AWG 8-16 AWG
Number of Decks 1
Wire Gauge (Min) 8 AWG
Wire Gauge (Max) 16 AWG
Current 60A
Number of Levels 1
Voltage 600V
Housing Color Blue
Approval Agency CE, CSA, IEC, NEMKO, UR
Termination Style Special, Hybrid
Current Rating 57A
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Voltage - Rated 6kV
Number of Positions 2
Type Bus Bar - Side
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series W
Published 2012
Operating Temperature -50°C~120°C
Physical
Material - Insulation Thermoplastic, Wemid
Weight 23.58g
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 12 Weeks
