1546148-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
TERM BLK NEMA 2POS 10.85MM GRAY
PDF
/
Inventory: 5737
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Copper
Contact Plating Zinc
Mount Cable, DIN Rail, Screw
Mounting Type Channel, DIN Rail Mount
Housing Material Polyester
Material - Insulation Polyester
Technical
Operating Temperature 150°C
Published 2007
Series 900, Buchanan
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Connector Type Screw, Terminal Block
Type NEMA Open Construction
Number of Positions 2
Color Grey
Number of Rows 1
Voltage - Rated 600V
Pitch 9.53mm
Orientation Straight
Current Rating 50A
Termination Style Tubular Screw
Voltage - Rated AC 600V
Number of Contacts 2
Housing Color Gray
Voltage 600V
ELV Compliant
Number of Circuits 2
Max Voltage Rating (AC) 600V
Number of Levels 1
Current 50A
Wire Gauge (Max) 8 AWG
Wire Gauge (Min) 22 AWG
Wire/Cable Gauge 8 AWG
Voltage - UL 600V
Wire Gauge or Range - AWG 8-22 AWG
Current - UL 50A
Max Supply Voltage (AC) 600V
Dimensions
Height 37.1094mm
Length 1.231 31.27mm
Width 17.78mm
Height (Max) 1.461 37.11mm
Terminal Width 10.9mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
