3273548
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CLIPLINE PTFIX RoHS Compliant Block of 6 Polyamide (PA) Nylon Terminal Block Middle 10-24AWG -60C~130C 32A 800V
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.2768
≥1 USD $4.2768
Inventory: 35
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type DIN Rail
Material - Insulation Polyamide (PA), Nylon
Technical
Operating Temperature -60°C~130°C
Series CLIPLINE PTFIX
Feature Block of 6
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Middle
Number of Positions 12
Termination Style Push In, Spring
Housing Color Gray
Number of Levels 1
Voltage - UL 600V
Wire Gauge or Range - AWG 10-24 AWG
Voltage - IEC 800V
Wire Gauge or Range - mm2 0.2-6mm2
Current - IEC 32A
Stripping Length 10mm ~ 12mm
Dimensions
Length 2.287 58.10mm
Height (Max) 1.276 32.40mm
Terminal Width 28.6mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
