RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description CLIPLINE PTFIX RoHS Compliant 2017 Block of 6 Terminal Block Middle 12-26AWG 5A 500V 0.835 21.20mm
PDF
/
Buying Options
Total Price: USD $3.04
Unit Price: USD $3.0448
≥1 USD $3.0448
Inventory: 76
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Terminal Width 31.2mm
Height (Max) 0.835 21.20mm
Length 1.110 28.19mm

Technical

Stripping Length 10mm
Current - IEC 24A
Wire Gauge or Range - mm2 0.14-4mm2
Voltage - IEC 500V
Current - UL 5A
Wire Gauge or Range - AWG 12-26 AWG
Voltage - UL 600V
Number of Levels 1
Housing Color Orange
Termination Style Push In, Spring
Number of Positions 12
Type Middle
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Block of 6
Series CLIPLINE PTFIX
Published 2017

Physical

Material - Insulation Polyamide (PA), Nylon
Mounting Type Direct Mount

Supply Chain

Factory Lead Time 6 Weeks
