3270423
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CLIPLINE PT RoHS Compliant 2016 Polyamide (PA) Nylon Terminal Block Marshalling Connector 12-26AWG 17.5A 500V 1.181 30.00mm
PDF
/
Inventory: 8893
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Terminal Width 11.0mm
Height (Max) 1.181 30.00mm
Length 0.480 12.19mm
Technical
Stripping Length 10mm
Current - IEC 17.5A
Wire Gauge or Range - mm2 0.14-2.5mm2
Voltage - IEC 500V
Wire Gauge or Range - AWG 12-26 AWG
Number of Levels 1
Housing Color Gray
Termination Style Push In, Spring
Color Grey
Number of Positions 3
Type Marshalling Connector
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series CLIPLINE PT
Published 2016
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Panel Mount
Supply Chain
Factory Lead Time 6 Weeks
