3270222
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CLIPLINE PT RoHS Compliant Polyamide (PA) Nylon Push In Spring Terminal Block Marshalling Connector 14-26AWG 10A 250V 2.480 63.00mm
PDF
/
Buying Options
Total Price: USD $19.57
Unit Price: USD $19.5712
≥1 USD $19.5712
≥10 USD $18.28728
≥100 USD $16.824368
≥500 USD $15.544232
≥1000 USD $14.812758
≥3000 USD $13.969454
Inventory: 103
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Terminal Width 8.3mm
Height (Max) 2.480 63.00mm
Length 2.520 64.00mm
Technical
Stripping Length 8mm ~ 10mm
Current - IEC 17.5A
Wire Gauge or Range - mm2 0.14-2.5mm2
Voltage - IEC 250V
Current - UL 10A
Wire Gauge or Range - AWG 14-26 AWG
Voltage - UL 300V
Number of Levels 4
Housing Color Gray
Termination Style Push In, Spring
Color Grey
Number of Positions 16
Type Marshalling Connector
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series CLIPLINE PT
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 4 Weeks
