3249172
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
CLIPLINE ST RoHS Compliant 2014 Polyamide (PA) Nylon Terminal Block Middle UL94V-0 28AWG 20A 300V
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
Inventory: 116
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 10.4mm
Length 1.260 32.00mm
Height 21.9964mm
Technical
Stripping Length 8mm
Current - IEC 24A
Wire Gauge or Range - mm2 0.08-4mm2
Voltage - IEC 800V
Wire Gauge or Range - AWG 12-28 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 28 AWG
Current 20A
Number of Levels 1
Voltage 300V
Housing Color Gray
Termination Style Push In, Spring
Current Rating 24A
Voltage - Rated 800V
Color Grey
Number of Positions 4
Type Middle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CLIPLINE ST
Published 2014
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type Direct Mount
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
