3244630
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
Phoenix Contact Non-Fused Terminal Block, RBO series , 1000 V, 520A, Bolt Termination, Grey, Single Level
PDF
/
Buying Options
Total Price: USD $31.58
Unit Price: USD $31.5832
≥1 USD $31.5832
Inventory: 34
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Material - Insulation Polyamide (PA), Nylon
Technical
Published 2015
Series CLIPLINE RBO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type NEMA Open Construction
Number of Positions 2
Max Operating Temperature 130°C
Min Operating Temperature -60°C
Color Grey
Voltage - Rated 1kV
Current Rating 520A
Termination Style Bolt and Nut
Housing Color Gray
Voltage 1kV
Number of Levels 1
Current 540A
Wire Gauge or Range - AWG 1000MCM (kcmil)-4 AWG
Wire Gauge or Range - mm2 25-300mm2
Current - IEC 520A
Dimensions
Height 99.2886mm
Length 6.457 164.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
