3076154
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
Phoenix Contact Non-Fused Terminal Block, RBO series , 1500 V, 520A, Bolt Termination, Black, Grey, Yellow
PDF
/
Inventory: 1147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 6.457 164.00mm
Height 99.2886mm
Technical
Current - IEC 520A
Wire Gauge or Range - mm2 25-300mm2
Wire Gauge or Range - AWG 1000MCM (kcmil)-4 AWG
Current 540A
Number of Levels 1
Voltage 1kV
Housing Color Black, Gray, Yellow
Termination Style Bolt and Nut
Current Rating 520A
Voltage - Rated 1.5kV
Color Black, Grey, Yellow
Number of Positions 8
Type NEMA Open Construction
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series CLIPLINE RBO
Published 2015
Physical
Material - Insulation Polyamide (PA), Nylon
Mounting Type DIN Rail
Mount DIN Rail
