3076086
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
Phoenix Contact Non-Fused Terminal Block, RBO series , 1500 V, 192A, Bolt Termination, Blue, Grey, Single Level
PDF
/
Inventory: 1174
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Material - Insulation Polyamide (PA), Nylon
Technical
Published 2015
Series CLIPLINE RBO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type NEMA Open Construction
Number of Positions 8
Color Blue, Grey
Voltage - Rated 1.5kV
Current Rating 192A
Termination Style Bolt and Nut
Housing Color Blue, Gray
Voltage 600V
Number of Levels 1
Current 175A
Wire Gauge (Max) 8 AWG
Wire Gauge (Min) 0 AWG
Wire Gauge or Range - AWG 2/0-8 AWG
Voltage - IEC 1.5kV
Wire Gauge or Range - mm2 6-70mm2
Current - IEC 192A
Dimensions
Height 74.4982mm
Length 7.244 184.00mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
